Spirosonic Smart Ultrasonic Spirometer

SKU: SpiroSonic SMART

SpiroSonic SMART is a compact, touchscreen ultrasonic spirometer offering research-grade digital accuracy in a portable design. With over 35 pulmonary parameters and voice-guided operation, it supports the diagnosis and monitoring of asthma, COPD, and occupational lung disease. Its low-flow resistance makes it ideal for children, the elderly, and patients with compromised lung function. Direct printing and multilingual tutorials make it a powerful, user-friendly tool for modern pulmonary care.

Key Features:

2 Year Warranty

Standard Manufacturer

Fast Delivery

Ships within 24 hours

Certified Quality Standards:

SpiroSonic SMART is an advanced ultrasonic spirometer designed to deliver hospital-grade pulmonary function testing in a compact and portable format. Using high-precision, multipath ultrasonic technology, it provides accurate, real-time measurements across more than 35 respiratory parameters – matching the capabilities of complex PC-based systems. With automatic internal calibration, low flow resistance, and interactive, voice-guided instructions in multiple languages, it’s optimized for use with children, elderly patients, and those with severe respiratory issues.

This all-in-one solution includes a vibrant touchscreen display, 4000+ measurement memory capacity, and seamless data synchronization via the SpiroReporter software. Clinicians can print diagnostic reports directly via USB or Bluetooth-connected printers and integrate environmental data using an optional USB weather station. Ideal for both clinical and field use, SpiroSonic SMART supports effective management of asthma, COPD, and occupational lung disease with simple cleaning protocols and intuitive operation.

Whether in hospitals, clinics, or occupational health settings, SpiroSonic SMART sets a new global standard for digital spirometry by combining portability, precision, and ease of use.

Volume Accuracy:
±2.5% or 50 mL (whichever is greater)
Flow Accuracy:
±2.5% or 50 mL/s (whichever is greater)
Flow Range:
±14 L/sec
Resolution:
3 mL/sec
Sample Rate:
100 Hz
Display:
QVGA 262k color touchscreen
Memory:
Stores over 4000 measurements
Measured Parameters:
FEV1, FVC, PEF, MVV, VC, TV, ERV, IC, FEF25-75, RR, VE, and 25+ more
Connectivity:
USB (Mini Type B for PC, Type A for printer), optional Bluetooth
Software:
SpiroReporter – diagnostics, reporting, archiving, HL7/GDT/BDT/XML compatible
Power Supply:
Internal 3.7V Li-Ion rechargeable battery via Mini USB (5V 500 mA)
Device Dimensions:
37 × 80 × 92 mm
Flow Tube Dimensions:
Ø30 × 165 mm
Device Weight:
184 g
Supported Languages (Voice Module):
English (US, AU), French, German, Italian, Spanish, Chinese, Hungarian, Korean, Croatian, Austrian
Optional Accessories:
USB Weather Station, Bluetooth Thermal Printer, USB Pulse Oximeter
doctor holding Spirosonic Smart Ultrasonic Spirometer
doctor holding Spirosonic Smart Ultrasonic Spirometer and inspecting readings
